3 – 64
3
3.4 BASIC OPERATIONS
.
..
Description of Test Items
1 SELF CHECK
1-1 SENSOR
Refer to (1) Checking Memory, Safety Switch, Various Currents and Voltages, and Communication
Lines in Section 8.1.1 Function Check on Test Menu.
1 Press .
The TEST Menu will appear.
2 Press .
The SELF CHECK Menu will appear.
3 Press .
The SENSOR Menu will appear and the operational status of
the scanner unit and the transmitter unit will appear.
1 Press .
The TEST Menu will be closed.
1-2 LINE CHECK
Refer to (1) Checking Memory, Safety Switch, Various Currents and Voltages, and Communication
Lines in Section 8.1.1 Function Check on Test Menu.
1 Press .
The TEST Menu will appear.
2 Press .
The SELF CHECK Menu will appear.
3 Press .
The LINE CHECK Menu will appear. If the transmitter-
receiver unit and navigation equipment are connected via
serial data lines, it can be checked whether data is transferred.
To Next Page
