3 – 70
3
3.4 BASIC OPERATIONS
.
..
5 PM (Performance Monitor)
Refer to (5) Checking Performance Monitor in Section 8.1.1 Function Check on Test Menu.
1 Press .
The TEST Menu will appear.
2 Press .
If the Performance Monitor is installed,“ON” in “5.PM” will
be set and the status of performance monitor will appear by the
[PM] bar-graph in the TEST Menu.
Press again. “5.PM” will be set to “ON” and the
[PM] indicator in the menu will disappear.
1 Press or .
The TEST Menu will be closed. If “5.PM” is set to “ON”, the status will be set to “OFF”
automatically.
6 ERROR LOGGING
Refer to (6) Checking Error Logging in Section 8.1.1 Function Check on Test Menu.
1 Press .
The TEST Menu will appear.
2 Press .
ERROR LOGGING Menu will appear. If any error is caused,
the type of the error will be memorized and displayed.
1 Press or .
The TEST Menu will be closed.
TEST
0
Exit
6
TEST
Procedures
TEST
0
Exit
5
5
TEST
Procedures
4.MAG CURRENT
OFF ON
OFF ON
TEST MENU
0.
EXIT
7.
1.
SELF CHECK
2.
PANEL TEST
3.
ARPA TEST
5.PM
6.
ERROR LOGGING
SYSTEM INFO
PM
TEST MENU
0.
EXIT
ERROR LOGGING
1.
ALL CLEAR
