3 – 85
6 Press when all NAV INFO item is made.
The EDIT Menu will reappear.
Note: Navigation information can have a maximum of 256 points plotted.
Note that the value of REMAIN POINTS (the number of points that can be still
plotted) is decreased whenever lines and marks are plotted.
3 CORRECT (Correct one position of navigational information)
1 Press .
3. will be selected. will appear
in the CURSOR ( ) at the upper right of the radar display.
2 Move the cross cursor mark to any line element or
mark to correct using the trackball, and click the
trackball section left button.
A dotted-line starting from the line or mark will be drawn as
the cross cursor moves.
3 Move the cross cursor to the point to correct using
the trackball, and click the trackball section left
button.
One element of the line or the mark will be moved.
4 DELETE (Delete one point in navigational information)
1 Press .
4. will be selected. will appear in
the CURSOR ( ) at the upper right of the radar display.
2 Move the cross cursor mark to any line element or
mark to delete using the trackball, and click the
trackball section left button.
One element of the line or the mark will be deleted.
NAV DELDELETE
