JRC JMA-9822-6XA User Manual

8 – 7
1 Press .
The ARPA TEST Menu will reappear.
2 Press .
The TEST Menu will reappear.
3 Press .
The TEST Menu will be closed.
(4) Check of Magnetron Current
The Magnetron Current can be checked through the level of the “MAG” indicator bar in the
TEST Menu.
1 Press .
The TEST Menu will appear.
TEST
Procedures
0
0
0
Exit
Quantization Level in Automatic Acquisition
Quantization Level on Medium and Short Ranges
Quantization Level on Long Range
Gate Size
Current Numbers of Targets Under Tracking
(Refer to “Vector Constant” in Section 8.5
ADJUSTMENTS)
(Refer to “Quantization Level” in Section
8.5 ADJUSTMENTS)
(Refer to “Quantization Level” in Section
8.5 ADJUSTMENTS)
(Refer to “Quantization Level”h in Section
8.5 ADJUSTMENTS)
(Refer to “Gate Size” in Section 5.10
ARPA SETTING)
Vector Constant
TEST MENU
0.
EXIT
ARPA TEST
STATUS
4
45
40
35
0
NARROW
