JUKI FX-3R User Manual

FX-3R Maintenance Guide
13-43
Rev. 1.00
• XL specification
Applicable cable
Part No. Part name
Connector
No.
Sensor block
connection
destination
Remarks
40047910 IN SENS CABLE ASM SBL1-1 SBL1-S1
40089929 BU PIN-L SENS CABLE ASM SBL1-2 SBL1-S2
SBL1-3 SBL1-S3
40047912 WAIT-L SENS CABLE ASM
SBL1-4 SBL1-S4
SBL1-5 SBL1-S5
40047913 STOP-L SENS CABLE ASM
SBL1-6 SBL1-S6
SBL1-7 SBL1-S7
40047914 COUT-L SENS CABLE ASM
SBL1-8 SBL1-S8
40047915 BU ORG-L SENS CABLE ASM SBL2-1 SBL2-S1
40047916 BU LOCK-L SENS CABLE ASM SBL2-2 SBL2-S2
40089930 BPIN-L RCV SENS CABLE ASM SBL2-3 SBL2-S3
40047917 TPN-L SENS CABLE ASM SBL2-4 SBL2-S4
40047918 AWC-L SENS CABLE ASM SBL2-5 SBL2-S5
−−−−− −−−−−−−−−−−−−−−−−−−−−−− −−−−− SBL2-S6 Not used
−−−−− −−−−−−−−−−−−−−−−−−−−−−− −−−−− SBL2-S7 Not used
−−−−− −−−−−−−−−−−−−−−−−−−−−−− −−−−− SBL2-S8 Not used
40047906 SBL2 RELAY CABLE ASM
Relay cable between SBL1 and
SBL2
40047920 OUT SENS CABLE ASM SBR1-1 SBR1-S1
40089931 BU PIN-R SENS CABLE ASM SBR1-2 SBR1-S2
SBR1-3 SBR1-S3
40047922 WAIT-R SENS CABLE ASM
SBR1-4 SBR1-S4
SBR1-5 SBR1-S5
40047923 STOP-R SENS CABLE ASM
SBR1-6 SBR1-S6
SBR1-7 SBR1-S7
40047924 COUT-R SENS CABLE ASM
SBR1-8 SBR1-S8
40047925 BU ORG-R SENS CABLE ASM SBR2-1 SBR2-S1
40047926 BU LOCK-R SENS CABLE ASM SBR2-2 SBR2-S2
40089932 BPIN-R RCV SENS CABLE ASM SBR2-3 SBR2-S3
40047927 TPN-R SENS CABLE ASM SBR2-4 SBR2-S4
40047928 AWC-R SENS CABLE ASM SBR2-5 SBR2-S5
−−−−− −−−−−−−−−−−−−−−−−−−−−−− −−−−− SBR2-S6 Not used
−−−−− −−−−−−−−−−−−−−−−−−−−−−− −−−−− SBR2-S7 Not used
−−−−− −−−−−−−−−−−−−−−−−−−−−−− −−−−− SBR2-S8 Not used
40047907 SBR2 RELAY CABLE ASM
Relay cable between SBR1 and
SBR2
