FX-3R Maintenance Guide
15-6
Rev. 1.00
Figure 15-2-4 Detachment of Cutter Main Unit
Cutter main unit
SL6062092TN
Hexagon socket head
cap bolt with washer
M6 L = 20
40084697
Spacer A
40084698
Spacer B
