FX-3R Maintenance Guide
16-2
Rev. 1.00
Part No. Part name Purpose Figure Remarks
E62607050A0A Master feeder
assembly
Pickup reference position offset
Same part as that used
for TF pick position
adjustment
40069368 X-MSC installation
jig
X-magnescale sticking jig
Newly set for FX-3.
40008106 MSC clearance jig For adjustment of magnet scale
detector head
T 0.25mm
T 0.35mm
T 0.45mm
40108676 X-frame support
jig
X-frame support part for roller
replacement
Newly set for FX-3R.
40108677 Roller support jig YS-linear base support part for
rail replacement
Newly set for FX-3R.
