FX-3R Maintenance Guide
5-20
Rev. 1.00
[List of Replacement Parts]
Table 5-13-2 Reference for PWB Positioning Hole
Part No. Part name Part No. Part name
1∗
1
PV150209000
5-PORT SOLENOID VALVE
7∗
1
PV150209000
5-PORT SOLENOID VALVE
2 PV150209300
5-PORT SOLENOID VALVE
8 PV150209300
5-PORT SOLENOID VALVE
3 PV150209300
5-PORT SOLENOID VALVE
9 PV150209300
5-PORT SOLENOID VALVE
4 40047772 WAIT-L SENSOR ASM 10 40047775 WAIT-R SENSOR ASM
5 40047774 STOP-L SENSOR ASM 11 40047777 STOP-R SENSOR ASM
6 40047773 COUT-L SENSOR ASM 12 40047776 COUT-R SENSOR ASM
∗
1
In the case of EN type, a solenoid valve (PV150209000) is provided in addition to those
provided as the standard specifications.
∗
2
In the figure, BU(EN), SHAPE Y, and STOPPER are solenoid valves; WAIT, STOP, and
C-OUT are sensor amplifiers.
To Next Page
