Table 16: AC Power Supply LEDs in EX9214 Switches

(Connued)

Feed

Mode

Descripon LEDs

AC-1 OK AC-2 OK DC OK PS FAIL

Two-

Feed

The power input to the AC appliance

inlet located on the chassis above the

power supply is connected and the

power input to the AC appliance inlet

on the power supply faceplate is not

connected; the input is within the

acceptable range, but the power

supply is not funconing normally

and is not providing power to the

switch chassis.

Green O O Red

The power input to the AC appliance

inlet on the power supply faceplate is

connected and the power input to

the AC appliance inlet located on the

chassis above the power supply is

not connected; the input is within

the acceptable range, but the power

supply is not funconing normally

and is not providing power to the

switch chassis.

O Green O Red

The power input to the AC appliance

inlet located on the chassis above the

power supply and the power input to

the AC appliance inlet on the power

supply faceplate are connected; the

inputs are within the acceptable

ranges and the power supply is

funconing normally and providing

power to the switch chassis.

Green Green Green O
