Table 29: Component LEDs on the Services Gateway
Possible Causes and Corrective
Actions
MeaningStateLED
Normal condition. No action is
required.
Indicates that the device is functioning
normally.
GreenStatus LED
Normal condition. No action is
required.
Indicates that the device is
starting up.
Indicates that the Reset Config
button is pressed.
Amber
Contact JTAC. See Juniper Networks
Technical Assistance Center on page
87.
Indicates that an error is detected in
the device.
Red
Major alarm indicates a critical
situation on the services gateway
that requires immediate action. See
Monitoring the SRX100 Services
Gateway Using Chassis Alarm
Conditions on page 83.
Indicates a major alarm.RedAlarm LED
Minor alarm condition requires
monitoring or maintenance. If left
unchecked, it might cause an
interruption in service or degradation
in performance. See Monitoring the
SRX100 Services Gateway Using
Chassis Alarm Conditions on page
83
Indicates a minor alarm.Amber
Normal condition. No action is
required.
Indicates that there are currently no
alarms.
Off
Normal condition. No action is
required.
Indicates that the device is functioning
normally.
GreenPower LED
Normal condition. No action is
required.
Indicates that the Power button has
been pressed and quickly released and
the device is gracefully shutting down.
Amber
Normal condition if the services
gateway is switched-off. No action is
required.
If you have not powered off the
services gateway, verify that the AC
power cord from the power source
to the device is not damaged, the
socket is in working condition, and
the device has an AC input voltage
between 100 and 240 VAC. See
Monitoring the SRX100 Services
Gateway Power System on page 84
Off indicates that the device is not
receiving power.
Off
82 Monitoring the SRX100 Services Gateway Components Using LEDs
