Juniper SRX210 Series - SRX210 Services Gateway Built-In Interfaces; Table 9: SRX210 Services Gateway Built-In Ethernet Port Leds

Table 9 on page 14 describes the built-in Ethernet port LEDs.
Table 9: SRX210 Services Gateway Built-In Ethernet Port LEDs
DescriptionStateColorFunctionNumber
Link is active. Data
communication is taking place.
BlinkingGreenTX/RX/LINK
LED
1
Link is active. No data
communication is taking place.
Steady
Link is inactive.OffUnlit
Power over Ethernet is on and the
connected power device is
receiving power.
SteadyGreenPoE LED2
PoE (Power over Ethernet) is on,
but the connected power device
is not receiving power (device
fault or not enough power).
SteadyYellow
PoE is off.OffUnlit
NOTE: The PoE LED is enabled only on the Power over Ethernet (PoE) model
of the SRX210 Services Gateway. For non-PoE models, the PoE LED remains
off.
Related
Documentation
SRX210 Services Gateway Specifications on page 7•
• SRX210 Services Gateway Front Panel and Back Panel Views (Low Memory, High
Memory, and PoE Versions) on page 9
• SRX210 Services Gateway Built-In Interfaces on page 14
• SRX210 Services Gateway Boot Devices and Dual-Root Partitioning Scheme on page 17
• SRX210 Services Gateway Cooling System on page 18
• SRX210 Services Gateway Power Supply on page 19
