Table 44: Component LEDs on the Services Gateway (continued)
Possible Causes and
Corrective ActionsMeaningStateLED
The device is not part of the
chassis cluster setup.
OffHA LED
Normal condition. No action
is required.
The Mini-PIM is present and
detected by the device.
GreenMini-PIM LED
See “Monitoring the SRX210
Services Gateway Using
Chassis Alarm Conditions”
on page 149.
The Mini-PIM is not present
or is not detected by the
device.
Off
Related
Documentation
Monitoring the SRX210 Services Gateway Chassis Using the CLI on page 145•
• Monitoring the SRX210 Services Gateway Using Chassis Alarm Conditions on page 149
• Monitoring the SRX210 Services Gateway Power System on page 152
• Using the Reset Config Button on the SRX210 Services Gateway on page 153
• Changing the Reset Config Button Behavior on the SRX210 Services Gateway on page 154
• Juniper Networks Technical Assistance Center on page 155
Monitoring the SRX210 Services Gateway Using Chassis Alarm Conditions
When the services gateway detects an alarm condition, the alarm LED on the front panel
turns red or amber as appropriate.
To view a more detailed description of the cause of the alarm , issue the show chassis
alarms CLI command.
For more information on the show chassis alarms command, see the following guides:
•
Junos OS Initial Configuration Guide for Security Devices
•
Junos OS Monitoring and Troubleshooting Guide for Security Devices
Table 45 on page 150 describes alarms that can occur for an SRX210 Services Gateway
chassis component.
149Copyright © 2012, Juniper Networks, Inc.
Chapter 20: Monitoring Hardware Components
