Figure 6: Airflow Through the Chassis
g031140
Rear
Fan
Air flow
Front
Related
Documentation
SRX210 Services Gateway Specifications on page 7•
• SRX210 Services Gateway Front Panel and Back Panel Views (Low Memory, High
Memory, and PoE Versions) on page 9
• SRX210 Services Gateway Power Supply on page 19
SRX210 Services Gateway Power Supply
The power supply for the SRX210 Services Gateway is external. You must use the power
supply adapter provided by Juniper Networks to provide power to the services gateway.
Figure 7 on page 20 shows the label for the 12 V power supply.
19Copyright © 2012, Juniper Networks, Inc.
Chapter 2: Hardware Components and Specifications
