Keithley 2016 - Page 158

:PERiod
:APERture<n>
:APERture?
:THReshold
:VOLTage
:RANGe <n>
:RANGe?
:REFerence <n>
:STATe <b>
:STATe?
:ACQuire
:REFerence?
:DIGits <n>
:DIGits?
Path to configure period.
Sets aperture for period measurements (0.01 to 1.0s)
Query frequency period aperture
Path to select the threshold voltage range:
Select threshold range (0 to 1010).
Query threshold range.
Specify reference (0 to 1).
Enable or disable reference.
Query state of reference.
Use input signal as reference.
Query reference value.
Specify measurement resolution (4 to 7).
Query resolution.
1.0s
10
0
OFF
7
:DIODe
:CURRent
:RANGe
[:UPPer] <NRf>
[:UPPer]?
Paths to configure diode test:
Path to select range.
Select range (0 to 1e-3)
Query range.
1e-3
:CONTinuity
:THReshold <NRf>
:THReshold?
Path to configure continuity test:
Set threshold resistance (1 to 1000).
Query threshold resistance.
10
:DISTortion Path to configure total harmonic distortion.
:RANGe Path to configure measurement range.
[:UPPer] <n> Select range (0 to 757.5). 757.5
[:UPPer]? Query range.
:AUTO <b> Enable or disable auto range. ON
:AUTO? Query auto range.
:DIGits <n> Specify measurement resolution (4 to 7). 6
:DIGits? Query resolution.
:AVERage Path to configure and control the filter.
:TCONtrol <name> Select filter type (MOVing or REPeat). (Note)
:TCONtrol? Query filter type.
:COUNt <n> Specify filter count (1 to 100). 10
:COUNt? Query filter count.
:STATe <b> Enable or disable filter. OFF
:STATe? Query state of digital filter.
:TYPE Select distortion measurement type (THD, THDN,
SINAD).
:TYPE? Query distortion measurement type.
Table 5-7 (cont.)
SENSe command summary
Command Description
Default
parameter
SCPI
5-16 SCPI Command Reference
