19-156 Return to Section Topics 2600AS-901-01 Rev. B / September 2008
Section 19: Remote Commands Series 2600A System SourceMeter® Instruments Reference Manual
Remarks • These attributes are used to read or write to the measurement event instrument summary
registers.
• Reading a status register returns a value. The binary equivalent of the returned value indicates
which register bits are set. The least significant bit of the binary number is bit 0, and the most
significant bit is bit 15.
• For example, assume value 6 is returned for the enable register. The binary equivalent is
0000000000000110. This value indicates that bit B1 (SMUA) and bit B2 (SMUB) are set.
• The used bits of the measurement event instrument summary registers are described as
follows:
• Bit B1, SMUA: Set bit indicates one or more enabled bits for the SMU A measurement register
is set.
• Bit B2, SMUB: Set bit indicates one or more enabled bits for the SMU B measurement register
is set.
Details See Status model (measurement event registers) in Appendix C.
Example Sets the SMUA bit of the measurement event instrument summary enable register:
status.measurement.instrument.enable =
status.measurement.instrument.SMUA
status.measurement.instrument.smuX.condition
status.measurement.instrument.smuX.enable
status.measurement.instrument.smuX.event
status.measurement.instrument.smuX.ntr
status.measurement.instrument.smuX.ptr
smuX = smua or smub
Attribute Measurement event SMU X summary register set.
Default 0
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
