status.operation.trigger_overrun.condition
status.operation.trigger_overrun.enable
status.operation.trigger_overrun.event
status.operation.trigger_overrun.ntr
status.operation.trigger_overrun.ptr
Attribute Operation status trigger overrun register set.
Default 0
TSP-Link
accessibility
This attribute can be accessed from a remote TSP-Link node.
Usage Reads condition, enable, event, NTR, and PTR registers:
operreg = status.operation.trigger_overrun.condition
operreg = status.operation.trigger_overrun.enable
operreg = status.operation.trigger_overrun.event
operreg = status.operation.trigger_overrun.ntr
operreg = status.operation.trigger_overrun.ptr
Writes to enable, NTR, and PTR registers:
status.operation.trigger_overrun.enable = operreg
status.operation.trigger_overrun.ntr = operreg
status.operation.trigger_overrun.ptr = operreg
Set operreg to one of the following values:
0 Clears all bits.
status.operation.trigger_overrun.SMUA Sets SMUA bit (B1).
status.operation.trigger_overrun.SMUB Sets SMUB bit (B2).
status.operation.trigger_overrun.TRIGGER_BLENDER Sets TRGBLND bit (B10).
status.operation.trigger_overrun.TRGBLND Sets TRGBLND bit (B10).
status.operation.trigger_overrun.TRIGGER_TIMER Sets TRGTMR bit (B11).
status.operation.trigger_overrun.TRGTMR Sets TRGTMR bit (B11).
status.operation.trigger_overrun.DIGITAL_IO Sets DIGIO bit (B12).
status.operation.trigger_overrun.DIGIO Sets DIGIO bit (B12).
status.operation.trigger_overrun.TSPLINK Sets TSPLINK bit (B13).
status.operation.trigger_overrun.LAN Sets LAN bit (B14).
operreg can also be set to the decimal weight of the bit to be set. Examples:
To set bit B1 (SMUA), set operreg to 2 (2
1
).
To set bit B2 (SMUB), set operreg to 4 (2
2
).
To set bit B13 (TSPLINK), set operreg to 8192 (2
13
).
To set two bits, set operreg to the sum of the decimal weights of both bits:
To set bits B1 and B2, set operreg to 6 (2 + 4).
