2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-227

Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands

tspnet.readavailable

Function Read the number of bytes waiting to be read.

TSP-Link

accessibility

This function can be accessed from a remote TSP-Link node.

Usage num_bytes = tspnet.readavailable(connection_id)

connection_id Integer value used as a handle for other tspnet

commands.

num_bytes The number of bytes available.

Remarks • This command checks to see if any data is available from the remote instrument. No data is

read. It is intended to allow TSP

scripts to continue to run without waiting on a remote

command to finish.

• Errors:

Invalid Specified Connection

Read Failed

Example x = tspnet.readavailable(myconnection)
