2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-253
Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
Example ConfigPulseIMeasureV(smua, 0, 5, 10, 0.001, 0.080, 1,
smua.nvbuffer1, 1)
Set up a pulse train that will use SourceMeter instrument Channel A. The pulse
amplitude will be 5A and will return to 0A after 1ms. The pulse will remain at 0A
for 80 ms and the voltage limit will be 10V during the pulse. The pulse train will
consist of only 1 pulse and this pulse will be assigned a tag index of 1.
See also InitiatePulseTest, InitiatePulseTestDual
Table 19-13
KIPulse TSP test script: ConfigPulseVMeasureI
TSP project name: KIPulse
TSP test script name: KIPulse
Function:
ConfigPulseVMeasureI
Usage:
f, msg = ConfigPulseVMeasureI
(smu,bias,level,limit,ton,toff,points,buffer,tag[,sync_in][,sync_out]
[,sync_in_timeout][,sync_in_abort])
Description Configures a voltage pulse train with a current measurement at each point.
Measurement(s) will be made at the end of the ton time. This function does not
cause the specified smu to output a pulse train. It simply checks to see if all of the
pulse dimensions are achievable and if so, assigns the indicated tag or index to
the pulse train. The InitiatePulseTest(tag) and
InitiatePulseTestDual(tag) functions are used to initiate a pulse train
assigned to a valid tag.
Table 19-12 (cont.)
KIPulse TSP test script: ConfigPulseIMeasureV
TSP project name: KIPulse
TSP test script name: KIPulse
Function:
ConfigPulseIMeasureV
Usage:
f, msg = ConfigPulseIMeasureV
(smu,bias,level,limit,ton,toff,points,buffer,tag[,sync_in][,sync_out]
[,sync_in_timeout][,sync_in_abort])
