2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-255
Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
Output
Data
Pulsed current measurements are stored in the reading buffer specified by the
buffer input argument.
Example ConfigPulseVMeasureI(smub, 0, 20, 1, 0.001, 0.080, 10,
smub.nvbuffer1, 2)
Set up a pulse train that will use SourceMeter instrument channel B. The pulse
amplitude will be 20V and will return to 0V after 1ms. The pulse will remain at 0V
for 80ms and the current limit will be 1A during the pulse. The pulse train will
consist of 10 pulses and the pulse train will be assigned a tag index of 2.
See also InitiatePulseTest, InitiatePulseTestDual
Table 19-14
KIPulse TSP test script: ConfigPulseIMeasureVSweepLin
TSP project name: KIPulse
TSP test script name: KIPulse
Function:
ConfigPulseIMeasureVSweepLin
Usage:
f, msg = ConfigPulseIMeasureVSweepLin
(smu,bias,start,stop,limit,ton,toff,points,buffer,tag[,sync_in]
[,sync_out][,sync_in_timeout][,sync_in_abort])
Description Configures a linear pulsed current sweep with a voltage measurement at each
point. Measurement(s) will be made at the end of the ton time. The magnitude
of the first pulse will be start amps. The magnitude of the last pulse will be stop
amps. The magnitude of each pulse in between will be step amps larger than the
previous pulse where:
step = (stop - start) / (points - 1)
This function does not cause the specified smu to output a pulse train. It simply
checks to see if all of the pulse dimensions are achievable and if so, assigns the
indicated tag or index to it. The InitPulseTest(tag) and
InitPulseTestDual(tag) functions are used to initiate a pulse train assigned
to a valid tag.
Table 19-13 (cont.)
KIPulse TSP test script: ConfigPulseVMeasureI
TSP project name: KIPulse
TSP test script name: KIPulse
Function:
ConfigPulseVMeasureI
Usage:
f, msg = ConfigPulseVMeasureI
(smu,bias,level,limit,ton,toff,points,buffer,tag[,sync_in][,sync_out]
[,sync_in_timeout][,sync_in_abort])
