2600AS-901-01 Rev. B / September 2008 Return to Section Topics 19-263
Series 2600A System SourceMeter® Instruments Reference Manual Section 19: Remote Commands
Return
values
f: A Boolean flag. This flag will be true when the pulse was successfully
configured, false when errors were encountered.
msg: A string message. If the f flag is false, msg will contain an error
message. Otherwise, msg will contain a string indicating successful
configuration.
Output
Data
Pulsed current measurements are stored in the reading buffer specified by the
buffer input argument.
Example ConfigPulseVMeasureISweepLog(smub, 0, 1, 10, 1, 10e-3,
20e-3, 10, smub.nvbuffer1, 6)
Set up a pulsed log sweep that will use SourceMeter instrument Channel B. The
pulsed sweep will start at 1V, end at 10V, and return to a 0V bias level between
pulses. Each pulsed step will be on for 10ms and then at the bias level for 20ms.
The current limit will be 1A during the entire pulsed sweep. The pulse train will be
comprised of 10 pulsed steps and the pulse train will be assigned a tag index of 6.
See also InitiatePulseTest, InitiatePulseTestDual
Table 19-17 (cont.)
KIPulse TSP test script: ConfigPulseVMeasureISweepLog
TSP project name: KIPulse
TSP test script name: KIPulse
Function:
ConfigPulseVMeasureISweepLog
Usage:
f, msg = ConfigPulseVMeasureISweepLog
(smu,bias,start,stop,limit,ton,toff,points,buffer,tag[,sync_in]
[,sync_out][,sync_in_timeout][,sync_in_abort])
