Keithley 2600a series User Manual

2600AS-901-01 Rev. B / September 2008 Return to Section Topics 22-7
Series 2600A System SourceMeter® Instruments Reference Manual Section 22: Performance Verification
Figure 22-1
Connections for voltage verification
2. Select the multimeter DC volts measuring function.
3. Select the Model 2602A/2612A/2636A single-channel display mode. Press the SRC key to
source voltage and make sure the source output is turned on.
4. Enable the Series 2600A 4-wire (remote sense) mode by pressing CONFIG then SRC, then
select V-SOURCE > SENSE-MODE > 4-WIRE.
5. Verify output voltage accuracy for each of the voltages listed in Table 22-2 (Model 2601A/
2602A) or Table 22-3 (Model 2611A/2612A/2635A/2636A). For each test point:
• Select the correct source range.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
IEEE-488
LINE RATING
100-240VAC
50, 60Hz
240VA MAX.
DIGITAL I/O
RS-232
LINE FUSE
SLOWBLOW
3.15A, 250V
TSP-Link
R
SENSE
LO LO HI
CHANNEL A
SENSE
HI
GUARD
A LO
LAN
NO AUTO-MDIX
SENSE
LO
LOHI
CHANNEL B
SENSE
HI
GUARD
!
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
IEEE-488
LINE RATING
100-240VAC
50, 60Hz
240VA MAX.
DIGITAL I/O
RS-232
LINE FUSE
SLOWBLOW
3.15A, 250V
TSP-Link
R
CAT I
SS
LO LO HIHI GGGG
CHANNEL A
!
LAN
NO AUTO-MDIX
!
!
CAT I
SSLO
LOHI
HIGG G G
CHANNEL B
!
Input HI
Input LO
Model 2636A Channel A
Connections Shown
LO
HI
Digital Multimeter
S LO
S HI
Input HI
Input LO
Model 2602A/2612A Channel A
Connections Shown
LO
HI
Digital Multimeter
S LO
S HI
