3. Wiring Diagram
4. Test Code
From the working principle, we can read the level of the sensor pin to judge whether there are people nearby.
/*
keyestudio ESP32 Inventor Learning Kit
Project 17.1 Invasion Alarm
http://www.keyestudio.com
*/
int pir = 5; //Define IO5 as PIR sensor pin
void setup() {
pinMode(pir,INPUT); //Set IO5 pin to input
Serial.begin(9600);
}
void loop() {
int pir_val = digitalRead(pir); //Read the PIR result and assign it to pir_val
Serial.print("pir_val:"); //Print “pir_val”
Serial.println(pir_val);
delay(500);
(continues on next page)
