Keysight 16860 Series Portable Logic Analyzer Service Guide 111
Removing, Replacing, or Returning 16860 Series Logic Analyzer Assemblies 6
7 Gently pull the cover upward to remove it.
8 Reverse this procedure to replace the cover, bezel, or hard drive.
When reinstalling the handle assembly, ensure that the screws are
torqued to 2.372 Newton meters (21 inch pounds) so that they do not
work themselves loose.
