Parameter Typical Return
DIO | DINPut | FAULt | INHibit | ONCouple |
OFFCouple
DIO, DINP, FAUL, INH, ONC, OFFC
Sets pin 1 to FAULt mode: DIG:PIN1:FUNC FAUL
[SOURce:]DIGital:PIN<1-7>:POLarity POSitive|NEGative
[SOURce:]DIGital:PIN<1-7>:POLarity?
Sets the pin polarity.
POSitive means a logical true signal is a voltage high at the pin. For trigger inputs and outputs,
POSitive means a rising edge.
NEGative means a logical true signal is a voltage low at the pin. For trigger inputs and outputs,
NEGative means a falling edge. The pin polarities are saved in non-volatile memory.
Parameter Typical Return
POSitive|NEGative POS or NEG
Sets pin 1 to POSitive polarity: DIG:PIN1:POL POS
5 SCPI Programming Reference
