6 Input/Output
6.1 RF Source
If you do not specify a filename, an error is generated.
If the waveform sequence file name is empty, an error is generated.If the specified
waveform sequence file cannot be found, an error is generated.
Edit Selected Sequence
This dialog lets you edit an existing sequence of waveform segments. A table of the
segments in the currently selected sequence displays, allowing you to insert
waveform segments or edit the characteristics of each segment.
Segment
This field in the table shows the segment number assigned to this row.
Waveform
This field in the table shows the file name for the waveform inserted into this row.
Use "Insert Waveform" on page 2004 to insert a waveform.
Repetitions
Lets you specify the number of times the currently selected waveform is played
within the sequence.
Preset 1
Min 1
Marker 1 – Marker 4
Lets you enable or disable Marker 1, 2, 3, or 4 for the currently selected waveform.
For a waveform sequence, you can enable and disable markers on a per-segment
basis, allowing you to output markers from some waveform segments within the
sequence, but not for others.
Notes No remote command, front panel only
Preset Enabled
Range Enabled | Disabled
Short Range Comms & IoT Mode User's &Programmer's Reference 2008
