3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Offset Freq
This column is the same as "Offset Freq" on page 932 in the Offset tab.
Abs Limit
Specifies an absolute limit value, which sets the absolute amplitude levels to test
against for each of the custom offsets. The list must contain 6 entries. If there is
more than one offset, the offset closest to the carrier channel is the first one in the
list. [:SENSe]:ACP:OFFSet[n]:INNer:LIST:TEST selects the type of testing to
be done at each offset.
You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet
[n]:INNer:LIST:STATe.
The query returns the 6 sets of real numbers that are the current absolute amplitude
test limits.
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:ABSolute < real>,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:ABSolute?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:ABS -10,-10,-10,-10,-10,-10
:ACP:OFFS2:INN:LIST:ABS?
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is the same as the Offset
F value
Modes Values
5G NR -2.2, -2.2, -2.2, -2.2, -2.2, -2.2 | -50.0,-50.0,-50.0,-50.0,-50.0,-50.0
All Others -8.45,-8.45,-8.45,-8.45,-8.45,-8.45 | -50.0,-50.0,-50.0,-50.0,-50.0,-50.0
State Saved Saved in instrument state
Min/Max -200.0 dBm/50.0 dBm
Rel Limit (Car)
Specifies a relative limit value for the carrier level. This sets the amplitude levels to
test against for the specified offsets.
The amplitude level is relative to the carrier amplitude. If multiple offsets are
available, the list contains 6 entries. The offset closest to the carrier channel is the
first one in the list. [:SENSe]:ACP:OFFSet[n]:INNer:LIST:TEST selects the type
of testing to be done at each offset.
Short Range Comms & IoT Mode User's &Programmer's Reference 899
