6 Input/Output
6.8 Trigger Output
6.8 Trigger Output
Accesses controls that configure the Trigger Output settings.
6.8.1 Trig 1 – 4 Out
Selects the type of output signal that will be output from the available Trig n Out
connectors, where n = 1, 2, 3, or 4.
Some instruments do not support Trig 2 Out through Trig 4 Out outputs, nor their
associated controls.
For most instruments, Trig 1 Out applies to the connector labeled Trigger 1, but for
VXT model M9420A, it is labeled Trigger 4.
The front panel includes separate controls for each available trigger: Trig 1 Out –
Trig 4 Out. The remote command can be used for any of the Trig n Out connectors,
by specifying the appropriate parameter (for example TRIG1, TRIG2, etc.).
NOTE
Option TARMed is
not
available in modular instruments.
Remote Command
:TRIGger[1]|2|…|4[:SEQuence]:OUTPut HSWP | MEASuring | MAIN | GATE |
GTRigger | OEVen | TARMed | SPOint | S1Marker | S2Marker | S3Marker |
S4Marker | PARB | FSYNc | OFF
See "Trigger Out Options" on page 2170
:TRIGger[1]|2|…|4[:SEQuence]:OUTPut?
Example
:TRIG:OUTP HSWP
:TRIG2:OUTP GATE
Notes Trig 2 Out is used as the source trigger out in EXM and VXT model M9420A
The available choices in EXM and VXT model M9420A are S1Marker, S2Marker, S3Marker,
S4Marker and OFF
For Power Amplifier Mode, Trig 2 Out is set to Source Marker2 when Burst Shape & Mask is ON. In this
case, Trigger 2 is used to output PA Enable Mask
Dependencies Trig 2 Out through Trig 4 Out are not supported in all models. In models that do not support them, the
Trig n Out control is blanked, and sending the SCPI command for this output generates an error,
“Hardware missing; Not available for this model number”
Querying Trig 2 Out through Trig 4 Out in models that do not support them returns OFF
For VXT models M9410A/11A/15A/16A and M9410E/11E/15E/16E:
–
When Trig n Out Device is ANALyzer, only MEASuring, MAIN and OFF are available
–
When Trig n Out Device is SOURce, only S1Marker, S2Marker, S3Marker, S4Marker,
PARB, FSYNc and OFF are available
2169 Short Range Comms & IoT Mode User's &Programmer's Reference
