Keysight N9010B - 3.4.1.1 Normal; 3.4.1.2 Decode Summary; 3.4.2 Windows

3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
View SCPI Windows
NORMal
"RRC Correlated" on page 437
"Transmit Mask" on page 437
"Raw Main Time" on page 437
"Impulse Response" on page 438
"Metrics" on page 437
"Decode Summary" on page 436
DECode
"Decoded Bits" on page 438
"Frame Info" on page 438
"Metrics" on page 437
View – Selection by Enum (Remote Command Only)
Remote Command
:DISPlay:HUWB:VIEW[:SELect] NORMal | DECode
:DISPlay:HUWB:VIEW[:SELect]?
Example
:DISP:HUWB:VIEW DECode
Preset
NORMal
State Saved Saved in instrument state
3.4.1.1 Normal
Windows: "RRC Correlated" on page 437, "Transmit Mask" on page 437, "Raw Main
Time" on page 437, "Impulse Response" on page 438, "Metrics" on page 437.
3.4.1.2 Decode Summary
Windows: "Decoded Bits" on page 438, "Frame Info" on page 438, "Metrics" on page
437
3.4.2 Windows
The windows provided by this measurement and their indices are listed below:
# Window
1 "RRC Correlated" on page 437
2 "Transmit Mask" on page 437
3 "Spectrum" on page 437
4 "Raw Main Time" on page 437
5 "Metrics" on page 437
6 "Decoded Bits" on page 438
