3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Example
:HUWB:STS:KEY 14148674D1D336AAF86050A814EB220F
:HUWB:STS:KEY?
Couplings Available when "PHY Mode" on page 501 is not Non-ERDEV, "STS Packet Configuration" on page 502 is
not No STS and Modulation Analysis is enabled
Must be a 32-character string, entered in hexadecimal format. If the string length is not 32, it is
truncated or padded with 0. If a non-hexadecimal character is included, that character is replaced by 0
Preset
14148674D1D336AAF86050A814EB220F
State Saved Saved in instrument state
Upper Part of V (96bits)
Sets the most significant 96 bits of the 128-bit value V in hexadecimal format used
for generating the STS.
Remote
Command
[:SENSe]:HUWB:STS:VUPPer <string>
[:SENSe]:HUWB:STS:VUPPer?
Example
:HUWB:STS:VUPPer 362EEB34C44FA8FBD37EC3CA
:HUWB:STS:VUPPer?
Couplings Available when "PHY Mode" on page 501 is not Non-ERDEV, "STS Packet Configuration" on page 502 is
not No STS and Modulation Analysis is enabled
Must be a 32-character string, entered in hexadecimal format. If the string length is not 32, it is
truncated or padded with 0. If a non-hexadecimal character is included, that character is replaced by 0
Preset
362EEB34C44FA8FBD37EC3CA
State Saved Saved in instrument state
Initial Count (32bits)
Sets the initial value for 32-bit counter of value V in hexadecimal format.
Remote
Command
[:SENSe]:HUWB:STS:VLOWer:COUNter <string>
[:SENSe]:HUWB:STS:VLOWer:COUNter?
Example
:HUWB:STS:VLOW:COUN 1F9A3DE4
:HUWB:STS:VLOW:COUN?
Couplings Available when "PHY Mode" on page 501 is not Non-ERDEV, "STS Packet Configuration" on page 502 is
not No STS and Modulation Analysis is enabled
Must be an 8-character string, entered in hexadecimal format. If the string length is not 8, it is
truncated or padded with 0. If a non-hexadecimal character is included, that character is replaced by 0
Preset
1F9A3DE4
State Saved Saved in instrument state
510 Short Range Comms & IoT Mode User's &Programmer's Reference
