3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Couplings When auto-coupled in a non-zero span, the center frequency step size is set to 10% of Span. When
auto-coupled in zero span, the center frequency step size is set to the equivalent -3 dB RBW value
Preset
AUTO
State Saved Saved in instrument state
Min/Max –/+ (the maximum frequency of the instrument)
That is, 27 GHz max freq instrument has a CF step range of +/- 27 GHz. Note that this is the maximum
frequency given the current settings of the instrument, so in External Mixing, for example, it is the
maximum frequency of the current mixer band
Status Bits/OPC
dependencies
non-overlapped
CF Step Auto
Remote
Command
[:SENSe]:FREQuency:CENTer:STEP:AUTO OFF | ON | 0 | 1
[:SENSe]:FREQuency:CENTer:STEP:AUTO?
Example
:FREQ:CENT:STEP:AUTO ON
:FREQ:CENT:STEP:AUTO?
Preset
ON
Couple CF and Channel
Turns coupling between CF and Channel on or off. See Table 15-11 in IEEE Std
802.15.4 for the coupling rule.
Remote Command
[:SENSe]:HUWB:FREQuency:COUPle[:STATe] OFF | ON | 0 | 1
[:SENSe]:HUWB:FREQuency:COUPle[:STATe]?
Example
:HUWB:FREQ:COUP ON
:HUWB:FREQ:COUP?
Preset
OFF
State Saved Yes
Range
OFF|ON
3.4.7 Marker
Accesses a menu that enables you to select, set up and control the markers for the
current measurement.
Short Range Comms & IoT Mode User's &Programmer's Reference 489
