6 Input/Output
6.1 RF Source
NOTE
To load a file from the hard drive into ARB memory, go to the Recall, Waveform
dialog
Segments in ARB Memory
This table shows you which files are loaded into the ARB memory and lets you select
a file for inclusion in the sequence.
Delete Segment From ARB Mem
Deletes a segment from ARB memory. This is the same as Delete Segment From
ARB Mem in the Recall, Waveform dialog.
Delete All From ARB Memory
Removes all segments from ARB memory. This is the same as Delete All From ARB
Memory in the Recall, Waveform dialog.
Delete Segment
Lets you delete the current segment from the waveform sequence.
Notes No remote command, front panel only
Waveform Utilities
Not available in E7760B.
Only appears if there is at least one Multi-pack license installed in the instrument.
On modular instruments, such as EXM , multi-pack license operations are only
allowed on the default module, that is, “TRX1” module for EXM.
For EXM, if access multi-pack license sub-menu from modules other than “TRX1”,
an advisory message like “Please go to “TRX1” to operate multi-pack license” will
display.
Add Waveform
Use this dialog to select and add waveforms. Pressing OK in this dialog adds the
currently highlighted waveform to the next available slot, and returns you to the
"Waveform Utilities" on page 2010 dialog.
Short Range Comms & IoT Mode User's &Programmer's Reference 2010
