6 Input/Output
6.1 RF Source
Remote Command
:SYSTem:LKEY:WAVeform:ADD <string>
or
:SYSTem:LICense[:FPACk]:WAVeform:ADD <string>
Example
:SYST:LKEY:WAV:ADD "mywaveform.wfm"
or
:SYST:LIC:WAV:ADD "mywaveform.wfm"
Notes The second form, :SYSTem:LICense[:FPACk]:WAVeform:ADD, is provided for consistency
with Keysight signal sources. You can use either form
Since adding a waveform segment to a Multi-Pack license causes the license slot to enter the trial
period of only 48 hours, pressing this key causes a confirmation dialog to be displayed to ensure you
do want to add the waveform segment to the Multi-Pack
If you attempt to license a waveform that is already licensed using another slot an error is generated
For EXM, if current module is not “TRX1” module, the key is grayed-out, and error message is
generated “-221 Setting conflict; Not allowed on current module. Go to “TRX1” to operate multi-pack
license” when invoking SCPI
Dependencies Only available if the currently selected file is a secure waveform requiring a license, and there is at
least one slot available within at least one multi-pack license. Unavailable if the waveform highlighted
is a secure waveform, but is already licensed
Replace Selected Waveform
Lets you replace the waveform in the currently selected slot with the waveform
currently selected in the Multi-Pack License Waveform Add view. Pressing OK in this
dialog replaces the waveform in the currently selected slot with that currently
highlighted, and returns you to the "Waveform Utilities" on page 2010 dialog.
Remote
Command
:SYSTem:LKEY:WAVeform:REPLace <int>, <string>
or
:SYSTem:LICense[:FPACk]:WAVeform:REPLace <int>, <string>
Example
:SYST:LKEY:WAV:REPL 1, "myotherwaveform.wfm"
or
:SYST:LIC:WAV:REPL 1, "myotherwaveform.wfm"
Notes The second command form, :SYSTem:LICense[:FPACk]:WAVeform:REPLace is provided for
consistency with Keysight signal sources. You can use either form
If you attempt to license a waveform that is already licensed using another slot an error is generated
Waveform slot number <int> is positive. If you attempt to input a slot number less than or equals 0, an
error is generated
For EXM, if current module is not “TRX1” module, the key is grayed-out, and error message is generated
“-221 Setting conflict; Not allowed on current module. Go to “TRX1” to operate multi-pack license”
when invoking SCPI
2011 Short Range Comms & IoT Mode User's &Programmer's Reference
