3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Remote Command
[:SENSe]:HUWB:MMS[:STATe] OFF | ON | 0 | 1
[:SENSe]:HUWB:MMS[:STATe]?
Example
:HUWB:MMS ON
:HUWB:MMS?
Couplings Available when PHY Mode is ERDEV HPRF and STS Packet Configuration is SP3
Preset
OFF
State Saved Yes
Range
OFF|ON
Configure Frame
Configures parameters for frame.
SHR Parameters
Code Index
Sets the code index for UWB synchronization header (SHR). The code index
determines the sequence that is spread to create the Si symbol. There are 32
possible codes: Not all code indexes are available for each channel. The selected
"Channel" on page 487 also determines the available codes.
For more information, see Table 15-4, Table 15-6 and Table 15-7 of the IEEE
802.15.4 standard.
Remote
Command
[:SENSe]:HUWB:SHR:CODE:INDex C1 | … | C32
[:SENSe]:HUWB:SHR:CODE:INDex?
Example
:HUWB:SHR:CODE:IND C2
Couplings There are 32 possible codes. Lengths vary according to "PHY Mode" on page 501:
# Length PHY Modes
Codes 1-8 31 Non-ERDEV
ERDEV-HPRF
Codes 9-24 127 All
Codes 25-32 91 ERDEV-BPRF
ERDEV-HPRF
Not all code indexes are available for each channel. The selected "Channel" on page 487 also
determines the available codes. For more information, see Table 15-4, Table 15-6 and Table 15-7 of
the IEEE 802.15.4 standard
Preset
C3
Short Range Comms & IoT Mode User's &Programmer's Reference 503
