Configuration and Programming

P/N 06-237058-001 3-9 February 2012

Figure 3-11. ARIES NETLink Isolate Menu Functions (Cont’d - Fig. 2 of 4)

1. ISOLATE

1, R-NAC

3. BACKPLANE

ENTER LOGICAL ADDRESS RANGE __ to __



R-NAC Module Isolation

1: Isolate 2: De-Isolate *



3, RELAY

ENTER LOGICAL ADDRESS RANGE __ to __



Relay Module Isolation

1: Isolate 2: De-Isolate *



5, CITY TIE

CITY TIE Module Isolation

1: Isolate 2: De-Isolate *



6, PMU

ENTER LOGICAL ADDRESS RANGE __ to __



Isolation PMU

1: Isolate 2: De-Isolate *



7, DACT

DACT Module Isolation

1: Isolate 2: De-Isolate *



2, R-NAC CIRCUITS

ENTER MODULE LOGICAL ADDRESS : *



1: Isolate 2: De-Isolate *



ENTER CIRCUIT NUMBER : *



4, RELAY CIRCUITS

ENTER MODULE LOGICAL ADDRESS : *



1: Isolate 2: De-Isolate *



ENTER CIRCUIT NUMBER : *



8. NIC

Network Interface Card Isolation

1: Isolate 2: De-Isolate *



Cont’d

Questions and Answers:

R
Raymond KlineAug 14, 2025
How to fix AC INPUT FAULT on Kidde Fire Systems Control Unit?
- P
  perezdavidAug 14, 2025
  If the AC INPUT FAULT is on for your Kidde Fire Systems Control Unit, it could be due to a loss or degradation of primary power. First, notify your commercial light and power company about the service loss. Then, check the connections to the Power Management Unit (PMU) Board TB1, using a voltmeter to ensure you're getting the nominal 120/240 Vac at TB1. If this doesn't resolve the issue, remove both secondary and primary power, disconnect all field wiring (after labeling them), and ensure the AC Selector Switch on the power supply unit is correctly set for your line voltage. After checking the switch, reinstall the board, reconnect the field wiring, and reapply power. Finally, perform functional tests to confirm the system is working.
