Configuration and Programming
February 2012 3-10 P/N 06-237058-001
Figure 3-12. ARIES NETLink Isolate Menu Functions (Cont’d - Fig. 3 of 4)
FOOTNOTES (Figure 3-12):
3 Control Modules. Purpose: To prevent selected LAM, RDCM, and ATM modules from displaying
messages, or from carrying out activation instructions issued by the ARIES NETLink control unit.
4 Globally Isolate Initiating Devices. Purpose: To isolate all inputs and/or all outputs with a
single operation.
1. ISOLATE
4. Control Modules
1. LAM
Enter the LAM Number (01-16) *
1. Inputs *
Global Isolation of Inputs
1. Isolate 2. De-Isolate *
Cont’d
3. ATM
5. Global Isolate
Enter the ATM Number (01-15) *
2. Outputs *
Global Isolation of Outputs
1. Isolate 2. De-Isolate *
2. RDCM
Enter the RDCM Number (01-15) *
Isolate ATM
1. Isolate 2. De-Isolate *
Isolate RDCM
1. Isolate 2. De-Isolate *
Isolate LAM
1. Isolate 2. De-Isolate *
