Configuration and Programming
P/N 06-237058-001 3-11 February 2012
Figure 3-13. ARIES NETLink Isolate Menu Functions (Cont’d - Fig. 4 of 4)
FOOTNOTES (Figure 3-13):
5 Execute a User-Defined Inputs/Outputs Isolation Routine. Purpose: To perform multiple
input and/or output isolations via a single menu selection. The inputs and/or outputs to be
isolated are assigned to an "isolation macro" that is defined via the ARIES NETLink remote
configuration software. The ARIES NETLink remote configuration software permits four
"isolation macros" to be defined. Each macro can process up to ten separate isolation commands.
The specific isolation commands are executed when an Isolation Macro option is selected. The
isolation lists can include any of the following: initiating devices, control modules, or control-unit-
based outputs individually or by address range. This includes automatic initiating devices,
monitor modules, control modules, releasing circuits, notification-appliance circuits,
combination notification-appliance/releasing circuits, and programmable relays. Refer to the
ARIES NETLink Configuration Tool User’s Guide, P/N 06-237059-001, for the procedure to
assign initiating devices, control modules, or control-unit-based outputs to the isolation macros.
Note: Selecting the isolation-macro option for a second time will execute a de-isolation routine for
all the devices and/or circuits that were isolated by the execution of the isolation macro. The
isolation macros toggle the devices in the command lists between the isolated and non-
isolated states.
6 De-Isolate Isolation Macro. Purpose: To de-isolate the multiple input and/or output isolations
performed via an isolation macro.
1. ISOLATE
7. NETWORK
6. Macros
1. MACRO1 1. Local Node
2. Remote Node
Isolation Macro 1
1: Isolate 2: De-Isolate *
2. MACRO2
Isolation Macro 2
1: Isolate 2: De-Isolate *
3. MACRO3
Isolation Macro 3
1: Isolate 2: De-Isolate *
4. MACRO4
Isolation Macro 4
1: Isolate 2: De-Isolate *
Isolate /De-Isolate Node
1. Isolate 2. De-Isolate
Enter Remote Node Number:
Isolate/De-Isolate Node
1. Isolate 2. De-Isolate
5, 6
To Next Page
