Figure 3-15. ARIES NETLink List Menu Functions (Cont’d - Fig. 2 of 5)
FOOTNOTES (Figure 3-15):
8 EOC Program. Purpose: To view the Event-Output-Control (EOC) part of the system
configuration file.
9 SLC Assignments. Purpose: To view the registered devices on the SLC.
2. LIST
5.PROGRAMMING
1. NAC 2. R-NAC 3. RELAY
1. EOC PROGRAM
2. SLC Assignments
3. On Board Circuits
5 Control Modules
4. Backplane
6. GLOBALS
7. NETWORK SETTINGS
ENTER SLC LOOP NUMBER (1-8) _ 
1.R-NAC
2.RELAY
3. CITY TIE
4. PMU
5. DACT
ENTER MODULE LOGICAL ADDRESS ___ 
ENTER MODULE LOGICAL ADDRESS ___ 
ENTER MODULE LOGICAL ADDRESS ___ 
1. RDCM CONFIG
2. LAM CONFIG
3. CALL FOR SERVICE
4. ATM ASSIGNMENTS
ENTER RDCM NUMBER (1-15)__ 
ENTER LAM NUMBER (1-16)__ 
8. ISOLATION MACRO
Figure 3-16
ENTER ISOLATION MACRO NUMBER: * (1-4)
5. SOFTKEYS
LIST SOFTKEY CONFIGURATION
ENTER SOFTKEY NUMBER: * (1-4)

Figure 3-16
SLC Devices from *__ TO ___  (1-255)
