Configuration and Programming
February 2012 3-24 P/N 06-237058-001
Figure 3-23. ARIES NETLink Set Menu Functions (Cont’d - Fig. 5 of 18)
FOOTNOTES (Figure 3-23):
14 Registration. Manually Register SLC Devices.
Purpose: The ARIES NETLink control unit needs to know which SLC addresses (of the 255 possible
addresses) will be occupied by a SmartOne detector, monitor module, relay module or control
module. The Registration Procedure enters an occupied address into the control-unit's configuration
memory for each SLC device that it encounters during execution. The SLC devices must be uniquely
addressed prior to execution of the Registration Procedure.
The Main Controller Board (MCB) recognizes the following default-operating parameters for these
SLC devices:
SLC Device Default Operating Parameters
Ionization Detectors 0.8% per foot Pre-alarm Threshold
1.0% per foot Alarm Threshold
Latching Operation
Activates General-Alarm List
Photoelectric Detectors 1.5% per foot Pre-alarm Threshold
2.0% per foot Alarm Threshold
Latching Operation
Activates General-Alarm List
Heat Detectors 120°F Pre-Alarm Threshold
135°F Alarm Threshold
Latching Operation
Activates General-Alarm List
ITLCO/CTLCO Off
Monitor Modules (AIs) Alarm-Initiating Device
Latching Operation
Activates General-Alarm List
3. SET
3. SLC Devices
Cont’d
*
3. Registration
Device Registration
ENTER SLC LOOP NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
4. De-Registration
Device De-Registration
ENTER SLC LOOP NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
5. Blink Control
Program Device Blink Control
ENTER SLC LOOP NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
Set Blink Control
1: Blink Off 2: Blink On *
*=
Level-2 (Installer) Password required .
14 15
16, 17
To Next Page
