Networking
February 2012 5-18 P/N 06-237058-001
Figure 5-15. Typical Multiple Level-2 Event-Type Display
The upper line will display the active Level-2 events. The lower line will summarize the numbers of
completed Level-1 and active Level-2 events.
Refer to Section 4-10.6.7 for what to do when Level-2 events are reported.
5-8.13.3 REMOTE LEVEL-3 AND LOWER-LEVEL EVENT DISPLAY
Remote Level-3 and lower-level events from a networked control unit are shown in the upper line of
the LCD display by the node-of-event origin, the activated device or circuit address, the change of
state, and the device or circuit type that reported the event. The lower line indicates the numbers of
active events for the following Level-3 through Level-5 event types:
• Pre-Alarms
• Alarm-Verification Countdowns
• Supervisory Events
•Troubles
Figure 5-16 shows the appearance of the display when more than one type of Level-3 through Level-
5 event is active.
Figure 5-16. Typical Multiple Lower-Level Event Display
The upper line will display the active lower-level events according to the priority of events as
described in Section 4-10.6.7
Only Level-3 events will scroll, if present. Level-4 events will scroll if there are no Level-3 events.
Supervisory and trouble events will scroll if there are no active pre-alarms or alarm verifications. The
lower line will summarize the numbers of active Levels-3 through Level-5 events as shown in
Figure 5-15.
Refer to Section 4-10.6.9 for what to do when Level-3 and lower-level events are displayed.
N:02 L5:010 ALARM ON PHOTO
DIS 00 CNTDN 00 ABT 01 ALM 02 PAS 00
Alarm Indication
Device Type Reporting Alarm
Node Number
No. of Network Alarms
No. of Activated Network Abort Stations
No. of Network Countdowns to Release in Progress
No. of Network Extinguishing-System Releases
Device Address
No. of Network
PAS Countdowns
L5:010 VERIFY ON PHOTO
PREALM 00 AVCNTDN 01 SPV 00 TBL 02
Event Indication
Device Type Reporting Alarm
No. of Network Troubles
No. of Network Supervisory Events
No. of Network Alarm-Verification Countdowns
No. of Network
Pre-Alarms
Device Address
