WORK LAMP (FRT/RR)
The work lamp uses a halogen bulb.
Do not touch the illuminating part of
the halogen bulb.
The bulb life can be shortened by
finger prints, dust and moisture, or
the bulb even can be broken. Clean
it with soft cloth.
Be careful of the following when re-
placing the halogen bulb:
Replace the bulb after it is cooled
down.
Do not touch the glass of the bulb.
Handle the bulb with care and be
careful not to scratch or rub it.
Do not let the bulb contact with liq-
uid when it is illuminated.
Wear protective glasses when re-
placing the bulb.
1. Turn the key switch to the "OFF"
position and unscrew the screw
from the mounting hole with a
cross-head screwdriver to sepa-
rate the front glass case.
H11O663A
(1) Work Lamp Glass Case
2. Unscrew the ground wire screw,
disconnect the connector, and
turn the bulb counterclockwise to
remove it. Then, install a new bulb
with the same capacity.
H11O664A
(1) Work Lamp Bulb
To Next Page
