CABIN LAMP
(1) Cabin Lamp Bulb
1. Fit a flat-bladed screwdriver into
the edge of the cabin lamp and pry
off the room lamp cover.
2. Remove the cabin lamp bulb by
pulling it up. Install a new bulb.
H11O666A
TURN SIGNAL LAMP (REAR)
(1) Turn Signal Lamp (RR)
1. The turn signal lamp(rear) is in-
stalled on the rear fender.
M55O7A1A
2. Unscrew the mounting bolts from
the inside of the rear fender.
(1) Protective Cover
(2) Mounting Bolt
M55O7A2B
To Next Page
