DIAGNOSTICS Checkout Procedures
10DEC05
DG4825-1
Page
126 of 180
17 If the status of a SENSOR does not match the table, do the corresponding checkout.
18 Press [LATCH POSITION].
19 If:
• DUPLEX CAM does not move, do the checkout for the CAM MOTOR M1
• HOOKS are not in the down position, do the checkout HOOKS on the EXTRACTION
BAR
• EXTRACTION BAR is not in the home position, do EXTRACTION BAR HOME
POSITION
20 Check the status of the SENSORS and LEDs.
21 If the status of a SENSOR does not match the table, do the corresponding checkout.
22 Press [UNLATCH].
SENSOR Status LED Checkout
EXTRACTION BAR SENSOR
S9
X DS28
illuminated
EXTRACTION BAR SENSOR
S9
CAM INNER SENSOR S10 X DS26
illuminated
CAM SENSORS S10 and S11
CAM OUTER SENSOR S11 DS27 not
illuminated
SENSOR Status LED Checkout
EXTRACTION BAR SENSOR
S9
X DS28
illuminated
EXTRACTION BAR SENSOR
S9
CAM INNER SENSOR S10 DS26 not
illuminated
CAM SENSORS S10 and S11
CAM OUTER SENSOR S11 X DS27
illuminated
To Next Page
