DIAGNOSTICS Error Codes
10DEC05
DG4825-1
Page
61 of 180
10014 - CASSETTE REAR SENSOR S3 blocked on load
10016 - Load CASSETTE: Retry attempt
Description: The CASSETTE REAR SENSOR S3 is blocked before a CASSETTE is
loaded.
Cause 1: The CASSETTE REAR SENSOR S3 malfunctioned.
Action: Check:
• status of the CASSETTE REAR SENSOR S3 - use Individual Component
Control
• LED DS22 on the MOTION SYSTEM CONTROL BOARD A1 changes status
• power to the CASSETTE REAR SENSOR S3
• condition of the CASSETTE REAR SENSOR S3
Description: The CASSETTE REAR SENSOR S3 did not detect the CASSETTE. The
DRIVE ROLLERS actuate 3 times to load the CASSETTE indicating this
error each time.
Cause 1: The CASSETTE REAR SENSOR S3 operates correctly, but another malfunction
occurred.
Action: Check:
• DRIVE ROLLERS rotate freely
• CASSETTE REAR SENSOR S3 for obstructions
• adjustment of the SLED CAM FOLLOWER
Cause 2: The CASSETTE REAR SENSOR S3 malfunctioned.
Action: Check:
• status of the CASSETTE REAR SENSOR S3 - use Individual Component
Control
• LED DS22 on the MOTION SYSTEM CONTROL BOARD A1 changes status
• power to the CASSETTE REAR SENSOR S3
• condition of the CASSETTE REAR SENSOR S3
To Next Page
