DIAGNOSTICS Using the Diagnostics
10DEC05
DG4825-1
Page
12 of 180
Functions of the “System Service Diagnostic” Screen
Table 1 Component Tests
BUTTON Description
[Individual Component Control]
Important
For the test procedure, see Individual Component
Control.
Allows you to actuate and check the status of:
• CAM MOTOR
• SLOW SCAN
• ERASE LAMPS
• CASSETTE DRIVE MOTOR
[Component Control: Step]
Important
For the test procedure, see Component Control: Step.
Allows you to check the status of the components by
executing the following steps:
1. Loading the CASSETTE
2. Loading the PLATE
3. Scanning the PLATE
4. Erasing the PLATE
5. Ejecting the PLATE
6. Ejecting the CASSETTE
To Next Page
