DIAGNOSTICS Using the Diagnostics
10DEC05
DG4825-1
Page
27 of 180
Important
The ERASE LAMPS energize for approximately 2 - 10 seconds. The marks display in the
“Erase Station” check boxes while the ERASE LAMPS are energized.
14 Touch [ERASE LAMPS ON].
15 Check the status of the SENSORS.
16 Does the status of the SENSORS match?
Yes No
Continue with the next test. 1. Check the error logs. See Checking the Error Logs.
2. See the Error Codes to determine the possible cause
and action for the problem.
3. Advance to the next test.
To Next Page
