Kodak DirectView CR 850 User Manual

DIAGNOSTICS Error Codes
10DEC05
DG4825-1
Page
65 of 180
Cause 2: The internal BAR CODE READER malfunctioned.
Action: 1. Check:
• alignment of the BAR CODE READER
• BAR CODE READER is not blocked
• connections to the BAR CODE READER
2. If the BAR CODE READER emits a beep when you insert a CASSETTE, but
the CASSETTE does not load, check the CONNECTOR RJ45 between the
BAR CODE READER and the MASTER CENTRAL PROCESSING UNIT
BOARD A2.
3. If the BAR CODE READER does not emit a beep when you load a
CASSETTE, check the CONNECTOR RJ45 between the BAR CODE READER
and the MOTION SYSTEM CONTROL BOARD A1.
