190
Sequencer operating mode
Sequencer Play - Main page
Page menu icon
Touch the page menu icon to open the menu. See “Page menu”
on page 211 for more information.
Song area
This is where the Song name is shown, together with its tempo
and meter parameters, and the current measure.
Song name
Displays the name of the selected Song. “NEWSONG” means
that a new (blank) Song is selected, and you can record it.
Touch the Song name to make the Song Select window appear,
allowing for selection of a different Song (see “Song Select win-
dow” on page 82).
To select a Song, you can also press the SELECT button in the
SEQUENCER 1 section of the control panel. Press SELECT a
second time to select a Song by dialing in its ID number (see
“Selecting a Song by its ID number” on page 83).
Meter
Current Time Signature.
Measure number
Current measure number.
Tempo
Metronome tempo. Select this parameter and use the TEMPO/
VALUE controls to change the tempo. As an alternative, when a
different parameter is selected, or you are in a different page,
keep the SHIFT button pressed and use the DIAL to change the
tempo of the sequencer.
Locate measure
When checked, the measure shown by this parameter is a tem-
porary start point of the song, instead of measure 1. When you
press the (HOME) button, or use the << (REWIND) button
to go back to the beginning, the Song returns to this point.
Metro
Check this box to turn the metronome on during playback.
Tempo (Tempo mode)
Use this menu to select the Tempo change mode.
Manual In this mode, you can change the Tempo using
TEMPO/VALUE section controls. The Song will
be played back using the manually selected
tempo.
Auto The Tempo recorded to the Song will be used.
Selected track info area
This line lets you see the Sound assigned to the selected track.
Not only it is shown on the main page, but also in several edit
pages.
Track name
Name of the selected track.
Sound name
Sound assigned to the selected track. Touch anywhere in this
area to open the Sound Select window, and select a different
Sound.
Sound bank
Bank the selected Sound belongs to.
Program Change
Program Change number sequence (Bank Select MSB, Bank
Select LSB, Program Change).
Sounds area
This area lets you see Sounds and octave transposition for the
eight tracks currently displayed.
Song track octave transpose
Non editable. Octave transpose of the corresponding track. To
edit the octave transpose, go to the “Mixer/Tuning: Tuning” edit
page (see page 96 for programming information).
Sound bank’s icon
This picture illustrates the bank the current Sound belongs to.
Touch an icon a first time to select the corresponding track
(detailed information are shown on the Selected Track Info area,
see above). Touch it a second time to open the Sound Select win-
dow.
Song name
Tempo
Measure number
Beat counter
SELECT << >>
SEQUENCER 1
Track name
Sound name
Sound bank
Program Change
Octave icon Sound bank’s icon
