17 SERVICE WORK ON THE ENGINE 149
100206-10
–
Remove screw plug
with oil screen
and the O-rings.
– Completely drain the engine oil.
– Thoroughly clean the parts and sealing area.
100207-10
–
Position oil screen
with the O-rings.
–
Mount and tighten screw plug
with the O-ring.
Guideline
Plug, oil screen M20x1.5 15 Nm
(11.1 lbf ft)
100208-10
–
Position oil screen
with the O-rings.
–
Mount and tighten screw plug
with the O-ring.
Guideline
Plug, oil screen M20x1.5 15 Nm
(11.1 lbf ft)
