KTM 690 SMC R User Manual

9 SERVICE SCHEDULE 59
9.1 Service schedule
Every 20,000 km (12,428 mi) or every 2 years
Every 10,000 km (6,214 mi) or annually or after every sporting use
Once after 1,000 km (621.4 mi)
Check that the electrical equipment is functioning correctly. ○ ● ●
Read out the fault memory using the KTM diagnostics tool. ○ ● ●
Check the measured service values with the KTM diagnostics tool. ● ●
Change the engine oil and filter, clean the oil screens. ( p. 145) ○ ● ●
Check the front brake linings. ( p. 93) ○ ● ●
Check the rear brake linings. ( p. 98) ○ ● ●
Check the brake discs. ( p. 90) ○ ● ●
Check the brake lines for damage and leakage. ○ ● ●
Check the rear brake fluid level. ( p. 96) ○ ● ●
Check the free travel of the foot brake lever. ( p. 94) ○ ● ●
Check that the shock absorber and fork are leak tight. If necessary and depending on use, service the fork and shock
absorber.
○ ● ●
Check the swingarm bearing. ● ●
Check the wheel bearing for play. ● ●
Check the tire condition. ( p. 108) ○ ● ●
Check the tire air pressure. ( p. 110) ○ ● ●
Check the spoke tension. ( p. 111) ○ ● ●
Check for rim run-out. ○ ● ●
Check the chain, rear sprocket, engine sprocket, and chain guide. ( p. 82) ● ●
Check the chain tension. ( p. 79) ○ ● ●

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
