KTM 690 SMC R User Manual

18 CLEANING, CARE 155
Special cleaner for glossy and matte paint finishes, metal and plastic surfaces
( p. 187)
– Lubricate the ignition/steering lock.
Universal oil spray ( p. 187)
18.2 Checks and maintenance steps for winter operation
Info
If you use the motorcycle in winter, you must expect salt on the roads. You should therefore take precautions against aggressive
road salt.
If the vehicle was operated in road salt, clean it with cold water after riding. Warm water would enhance the corrosive effects of
salt.
401060-01
– Clean the motorcycle. ( p. 153)
– Clean the brake system.
Info
After EVERY trip on salted roads, thoroughly wash the brake calipers and brake
linings with cold water and dry carefully. This should be done after the parts are
cooled down and while they are installed.
After use on salted roads, clean the motorcycle thoroughly with cold water and
dry it properly.
– Treat the engine, the swingarm, and all other bare or galvanized parts (except brake
discs) with a wax-based anti-corrosion substance.
Info
To prevent serious reduction of the braking efficiency, make sure no
anti-corrosion substance gets on to the brake discs.

KTM 690 SMC R Specifications

General

Engine Type	Single-cylinder, 4-stroke
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Brake	Single 320 mm disc, 4-piston caliper
Rear Brake	Single 240 mm disc, 1-piston caliper
ABS	Bosch 9.1 MP (lean angle sensitive)
Fuel Tank Capacity	13.5 liters
Dry Weight	147 kg
